Features
- Highly sensitive touchscreen and original user-intuitive pen software
- Ideal tool for meetings, videoconferencing, presentations, corporate training, classrooms lessons and other.
- Uniformly bright screen with low energy consumption
- Streamlined communications via Direct Multifunction printer connection.
Specifications
- LCD Panel : 70-inch widescreen (176.6cm diagonal) UV2A LCD and 60-inch widescreen (152.5 cm diagonal) UV2A LCD
- Resolution : 1,920 x 1,080 pixels
- Display colors : 1,064 million colours
- Pixel pitch (H x V) : 0.802 mm (70-inch)/0.692 mm (60-inch)
- Brightness : 300 cd/m2 (70-inch) / TBD(60-inch)
- Constrast Ratio : 3000 : 1 (70-inch) / TBD (60-inch)
- Viewing Angle (H/V) : 160 degree/160 degree (CR > 10)
- Active Screen Area (W x H) : 1538.9 x 865.6 mm (70-inch) and 1329.1 x 747.6mm (60-inch)
- Response Time (Average) : 6 ms (gray to gray, avg.)
- Type / Touch Panel Technology : Infrared blocking detection method
- PC Connector : USB (1.1 standard)
- Power Supply : PC through USB port
- USB driver / OS : OS: Windows XP (32-bit/64-bit ver.), Windows Vista (32-bit/64-bit ver.), Windows 7 (32-bit / 64-bit ver.)
- Computer Input (Video) : Analogue RGB (0.7 Vp-p) [75 power], Digital (conforms to DVI 1.0 standards)
- Computer Input (Synchronization) : Horizontal/Vertical separetion (TTL: Positve/Negative), sync on green, Composite sync (TTL: Positve/Negative)
- Computer Input (Plug & Play) : VESA DDC2B
- Computer Input (Power Management) : VESA DPMS, DVI DMPM
- Video Colour System : With optional PN-ZB01: NTSC (3.58MHz, 4.43MHz), PAL, PAL60, SECAM
- Input Terminals (Component) : PC analogue: Mini-D-sub 15-pin x 1, HDMI x 1*2, 3.5 mm-diameter mini stereo jack x 1, RS-232C D-sub 9-pin x 1
- Input Terminals (Component) : With optional PN-ZB01: PC digital: DVI-D 24-pin x 1, PC analogue: BNC x 1*5*6, Video: BNC x 1, S-Video x 1, Component video: BNC (Y, Cb/Pb, Cr/Pr) x 1*5, Audio: RCA pin (L/R) x 2*5
- Input/Output Terminals : With optional PN-ZB01: LAN port
- Output Terminals : Audio: RCA pin (L/R) x 1, RS-232C D-sub 9-pin x 1
- Output Terminals : With optional PN-ZB01: PC digital: DVI-D 24-pin x 1, External speaker 7W + 7W (6 power)
- Power Supply : 100V - 240V AC, 50/60 Hz
- Power Consumption : 240W (70-inch) / TBD (60-inch)
- Environmental Conditions : Operating Temperature : 5 celsius~ 35 celsius
- Operating Humidity : 20 ~ 80%RH
- Dimensions (approx.) W x D x H : 1648 x 116 x 982 mm (70-inch) / 1440 x 100 x 855 (60-inch)
- Weight (approx.) : 70 kg (70-inch) / TBD (60-inch)
- Main Accessories : Touch pen, battery (AAA size), pen tip (for touch pen), eraser, holder, power code (approx. 3m), remote control unit and batteries (AA size x 2), CD-ROM, setup manual, stand hole protection cover x 2, vertical sticker x 2 (for operation panel & logo), blank sticker x 1, cable clamp x 2, USB cable (3.5m) x1
